LM300WQ6 SLA1 30 Inch LCD TV Panel with Hard Coating and 350CD Brightness for High-Quality Display

LM300WQ6 SLA1 30 Inch LCD TV Panel with Hard Coating and 350CD Brightness for High-Quality Display

LM300WQ6 SLA1 30 Inch LCD TV Panel with Hard Coating and 350CD Brightness for High-Quality Display

Brand Name: LG
Model Number: LM300WQ6-SLA1
MOQ: 10pcs
Price: Negotiation
Payment Terms: T/T,W,Western Union,MoneyGram
Supply Ability: 3000pcs per week
Detail Information
Product Description
Detail Information
Place of Origin:
China
Certification:
Rohs,CE,FCC
Quality:
Brand New Original
Package:
Original Industrial Packing
Packaging Details:
Industrial packing
Highlight:

flat screen tv panel

,

lcd tv display panel

Product Description
LM300WQ6 SLA1 30-Inch LCD Screen with Hard Coating
Product Overview

LG 30-inch brand new original LCD panel LM300WQ6-SLA1 featuring WQXGA resolution (2560*1600 pixels), 350 cd/m² brightness, and 92% color gamut coverage. This industrial-grade display panel is designed for professional applications requiring high resolution and reliable performance.

Technical Specifications
Brand LG Display
Model LM300WQ6-SLA1
Diagonal Size 30.0 inch
Display Type a-Si TFT-LCD, LCM
Resolution 2560(RGB)*1600 [WQXGA]
Pixel Configuration RGB Vertical Stripe
Active Area 641.28*400.8 mm
Outline Dimensions 677.3*436.8*18.5 mm
Surface Treatment Antiglare, Hard coating (3H)
Brightness 350 cd/m² (Typical)
Contrast Ratio 1000:1 (Typical)
Response Time 7/7 ms (Typical Tr/Td)
Viewing Angle 89/89/89/89 (CR≥10)
Operating Mode AH-IPS, Normally Black, Transmissive
Color Support 1.07B colors, 104% (CIE1931)
Light Source GB-r LED, 30K hours
Weight 4.15/4.36 kg (Typical/Maximum)
Frame Rate 60Hz
Touch Panel Without
Interface 92 pins LVDS (4 ch, 10-bit)
Power Supply 12.0V (Typical)
Operating Temperature 0°C to 50°C
Storage Temperature -20°C to 60°C
Key Features
  • High-resolution WQXGA display (2560*1600)
  • Advanced AH-IPS technology for superior color accuracy
  • Hard coating (3H) with antiglare surface treatment
  • Wide viewing angles (89/89/89/89)
  • High brightness of 350 cd/m²
  • Extended LED backlight lifespan (30,000 hours)
  • Industrial-grade reliability and performance
Quality Assurance: All original products undergo comprehensive testing before shipment. Detailed specification documents are available upon request - please contact us for additional technical information.
