BOE LCD Model Widescreen LCD Computer Monitors 10.1" 1280*800 Pixels NV101WXM-N51 For Notebook

We visited their factory many times.Their workshop is very big and e ink display module are really great!

—— Chris

Our company have placed orders to Ridafone many times.They develop and produce all e ink LCD display items in good quality.

—— Picado Freddy

I'm Online Chat Now

BOE LCD Model Widescreen LCD Computer Monitors 10.1" 1280*800 Pixels NV101WXM-N51 For Notebook

China BOE LCD Model Widescreen LCD Computer Monitors 10.1" 1280*800 Pixels NV101WXM-N51 For Notebook supplier
BOE LCD Model Widescreen LCD Computer Monitors 10.1" 1280*800 Pixels NV101WXM-N51 For Notebook supplier BOE LCD Model Widescreen LCD Computer Monitors 10.1" 1280*800 Pixels NV101WXM-N51 For Notebook supplier

Large Image :  BOE LCD Model Widescreen LCD Computer Monitors 10.1" 1280*800 Pixels NV101WXM-N51 For Notebook

Product Details:

Place of Origin: CHINA
Brand Name: BOE
Certification: Rohs,CE,FCC
Model Number: NV101WXM-N51

Payment & Shipping Terms:

Minimum Order Quantity: 1pcs
Price: Negotiation
Packaging Details: Industrial packing
Delivery Time: 4-5 working day
Payment Terms: T/T,W, Western Union, MoneyGram
Supply Ability: 3000pcs per week
Contact Now
Detailed Product Description
Quality: Brand New Original Package: Original Industrial Packing
Material: Glass Oled Color: 16.7m Colors
Model: WLED Style: Wide Screen High Resolution 1280*800
Brightness: 250cd Connector: 30
Contrast Ratio: 800:1 Working Time: 30k Hours

  • Brand
    BOE
  • Model
    NV101WXM-N51 (BOE070B)
  • Diagonal Size
    10.1 inch
  • Type
    a-Si TFT-LCD, LCM
  • Pixel Format
    1280(RGB)×800 [WXGA]
  • Configuration
    RGB Vertical Stripe
  • Active Area
    216.96(H)×135.6(V) mm
  • Outline Dim.
    228.21(H)×148.86(V) ×4.59(D) mm
  • Bezel Area
    -
  • Treatment
    Glare (Haze 0%), Hard coating (2H), Antireflection
  • Luminance
    250 cd/m² (Typ.)
  • Contrast Ratio
    800:1 (Typ.) (TM)
  • View Direction
    Symmetry
  • Response Time
    25 (Typ.)(Tr+Td)
  • Viewing Angle
    85/85/85/85 (Typ.)(CR≥10)
  • Operating Mode
    IPS, Normally Black, Transmissive
  • Support Color
    16.7M 50% (CIE1931)
  • Light Source
    WLED , With LED Driver
  • Form Style
    Slim (PCBA Bent, Depth ≤3.0mm)
  • Designed For
    BOE LCD Model Widescreen LCD Computer Monitors 10.1" 1280*800 Pixels NV101WXM-N51 For Notebook
  • Frame Rate
    60Hz
  • Touch Panel
    Without
  • Interface Type
  • 30 pins eDP (2 Lanes) , Connector
  • Power Supply
  • 3.3V (Typ.)
  • Environment
  • Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C

BOE LCD Model Widescreen LCD Computer Monitors 10.1" 1280*800 Pixels NV101WXM-N51 For Notebook

The NV101WXM-N51 (Product Code: BOE070B) is a 10.1 inch diagonal a-Si TFT-LCD display panel product from BOE Technology Group Co., Ltd. (hereafter called BOE), with an integral WLED backlight system, With LED Driver , without touch screen. It features an operating temperature range of 0 ~ 50°C , a storage temperature range of -20 ~ 60°C . It's general features are summarized by einklcd in the following: Glare Surface, Wide Viewing Angle, Landscape type, White LED Backlight, Wide Aspect Ratio, Signal Interface Position Reverse , eDP1.3. Based on its features, einklcd recommend that this model be applied to Laptop etc. According to the information stored in einklcd this model mass production on Q2, 2017, Now this model is in production. . We inputted this model's specification on Apr 27 2018 for the first time. If you want to embed NV101WXM-N51 LCM in your future product, einklcd strongly recommend that you should contact with BOE or it's agent to learn lateast production and specification detail. The NV101WXM-N51 production status marked on einklcd.com is for reference only and should not be used as the basis for the user's decision making.

                         All our LCD LED screen monitor module panel products will be full test one by one before sending .
