500cd/m2 Industrial Computer Monitor Innoux 10.4'' 1024*768 Pixels G104X1-L04

Brand Name:	INNOLUX
Model Number:	G104X1-L04
MOQ:	10pcs
Price:	Negotiation
Packaging Details:	Industrial packing
Payment Terms:	T/T,W, Western Union, MoneyGram

Detail Information

Product Description

Detail Information

Place of Origin:

KOREA

Certification:

Rohs,CE,FCC

Quality:

Brand New Original

Package:

Original Industrial Packing

Material:

Glass Oled

Color:

16.7M Colors

Model:

Style:

Wide Screen High Resolution 1024*768

Brightness:

350cd

Connector:

30pin

Contrast Ratio:

1000:1

Working Life:

30K Hours

Supply Ability:

3000pcs per week

Highlight:

industrial panel pc touch screen

industrial computer monitor

Product Description

Panel Brand
Innolux
Panel Model
G104X1-L04

Panel Size
10.4"
Panel Type
a-Si TFT-LCD, LCM

Resolution
1024(RGB)×768 , XGA
Pixel Format
RGB Vertical Stripe

Display Area
210.4(W)×157.8(H) mm
Bezel Opening
215.4(W)×161.8(H) mm

Outline Size
225.5(W)×176.3(H) ×9.2(D) mm
Surface
Antiglare

Brightness
500 cd/m² (Typ.)
Contrast Ratio
1000:1 (Typ.) (TM)

Viewing Angle
88/88/88/88 (Typ.)(CR≥10)
Display Mode
Super MVA, Normally Black, Transmissive

Best View on
Symmetry
Response Time
14/11 (Typ.)(Tr/Td)

Display Colors
262K/16.2M 55% (CIE1931)
Lamp Type
WLED , 50K hours , With LED Driver

Frequency
60Hz
Touch Screen
Without

Panel Weight
430±50g
Application

Signal Interface
LVDS (1 ch, 6/8-bit) , 30 pins , Connector

Input Voltage
3.3V (Typ.)

Environment
Operating Temp.: -30 ~ 80 °C ; Storage Temp.: -30 ~ 80 °C
G104X1-L04 is a 10.4" diagonal a-Si TFT-LCD display panel product from Innolux Corporation (hereafter called Innolux), with an integral WLED backlight system, With LED Driver , without touch screen. It features an operating temperature range of -30 ~ 80°C , a storage temperature range of -30 ~ 80°C , and the maximal vibration level of 1.5G (14.7 m/s²). It's general features are summarized by EINKLCD in the following: Antiglare Surface, 6/8 bit Selectable, Wide Viewing Angle, Landscape type, Wide Temperature, Lamp Repaceable, White LED Backlight, Lamp life ≥ 50K hours, 180 Reverse , Rev.C1:Haze 25%; Rev.C2:Haze 22%. Based on its features, Einklcd recommend that this model be applied to Industrial etc. According to the information stored in einklcd this model mass production on Q1, 2010, Now this model is in production. We inputted this model's specification on Mar 23 2013 for the first time, and the latest update on Mar 26 2019. If you want to embed the LCM in your future product, einklcd strongly recommend that you should contact with Innolux or it's agent to learn lateast production and specification detail of G104X1-L04. The production status marked on einklcd.com is for reference only and should not be used as the basis for the user's decision making.

It's 500cd/m2 lcd MODEL for industrial lcd ,computer,all-in-one computer,desktop,laptop lcd.

All our LCD LED screen monitor module panel products will be full test one by one before sending .
