M270DTN01.3 2560*1440 130 Pin AUO 27" 350CD/M2 laptop lcd screen

We visited their factory many times.Their workshop is very big and e ink display module are really great!

—— Chris

Our company have placed orders to Ridafone many times.They develop and produce all e ink LCD display items in good quality.

—— Picado Freddy

I'm Online Chat Now

M270DTN01.3 2560*1440 130 Pin AUO 27" 350CD/M2 laptop lcd screen

M270DTN01.3 2560*1440 130 Pin AUO 27" 350CD/M2 laptop lcd screen
M270DTN01.3 2560*1440 130 Pin AUO 27" 350CD/M2 laptop lcd screen M270DTN01.3 2560*1440 130 Pin AUO 27" 350CD/M2 laptop lcd screen

Large Image :  M270DTN01.3 2560*1440 130 Pin AUO 27" 350CD/M2 laptop lcd screen

Product Details:
Place of Origin: China
Brand Name: AUO
Certification: CE,FCC,ROSH,UL,REACH
Model Number: M270DTN01.3
Payment & Shipping Terms:
Minimum Order Quantity: 10pcs
Price: Negotiation
Packaging Details: industrial package
Delivery Time: 3-4 days
Payment Terms: Western Union, MoneyGram, T/T
Supply Ability: 20000pcs per week
Detailed Product Description
Material: Glass Size: 27inch
Constraction: 1000:1 Pixels: 2560*1440
Contactor: 130pin Working Life: 30k Hours
Display Colors: 16.7M Weight: 2.39kg
High Light:

350CD/M2 Laptop Lcd Display

,

M270DTN01.3

Panel Brand
Panel Size
Resolution
Display Area
Outline Size
Brightness
Viewing Angle
Best View on
Display Colors
Frequency
Weight
AUO
27.0"
2560(RGB)×1440, Quad-HD, 108PPI
596.736(W)×335.664(H) mm
608.8(W)×354.66(H) ×15.08(D) mm
350 cd/m² (Typ.)
85/85/80/80 (Typ.)(CR≥10)
-
16.7M 98% sRGB
144Hz
2.39Kgs (Typ.)
Panel Model
Panel Type
Pixel Format
Bezel Opening
Surface
Contrast Ratio
Display Mode
Response Time
Lamp Type
Touch Screen
Application
M270DTN01.3
a-Si TFT-LCD , LCM
RGB Vertical Stripe
-
Antiglare, Hard coating (3H)
1000:1 (Typ.) (TM)
TN, Normally White, Transmissive
3.5/1.5 (Typ.)(Tr/Td)
18S4P WLED , 30K hours , Without Driver
Without







Signal Interface LVDS (8 ch, 8-bit) , 130 pins Connector
Input Voltage 12.0V (Typ.)
Environment Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C





AUO 27inch Destop monitor Gaming lcd M270DTN01.3 2560*1440Pixels 108PPI 130pin 350CD/m2 oringial brand new



M270DTN01.3 2560*1440 130 Pin AUO 27" 350CD/M2 laptop lcd screen 0



AU Optronics Corp. (hereafter called AUO) M270DTN01.3 is a 27.0 inch diagonal a-Si TFT-LCD display panel product, with an integral WLED backlight system, without backlight driver, without touch screen. It features an operating temperature range of 0 ~ 50°C , a storage temperature range of -20 ~ 60°C , and the maximal vibration level of 1.5G (14.7 m/s²). It's general features are summarized by einklcd in the following: sRGB, 3-side boderless, 144Hz, 3D Display, WLED Backlight, Matte, G-Sync , TCO 6.0 Compliance, 144Hz, 3-side Borderless, G-Sync. Based on its features, einklcd recommend that this model be applied to Desktop Monitor, Gaming etc. According to the information stored in einklcd this model mass production on Q4, 2014, Now this model is in production.  We inputted this model's specification on Mar 4 2015 for the first time, and the latest update on Feb 14 2020. If you want to embed M270DTN01.3 LCM in your future product, einklcd strongly recommend that you should contact with AUO or it's distributor to learn lateast production and specification detail. The M270DTN01.3 production status marked on einklcd.com is for reference only and should not be used as the basis for the user's decision making.
