6.5" 640×480 VGA 122PPI 800cd/m2 Industrial Lcd Monitor G065VN01 V2

We visited their factory many times.Their workshop is very big and e ink display module are really great!

—— Chris

Our company have placed orders to Ridafone many times.They develop and produce all e ink LCD display items in good quality.

—— Picado Freddy

I'm Online Chat Now

6.5" 640×480 VGA 122PPI 800cd/m2 Industrial Lcd Monitor G065VN01 V2

6.5" 640×480 VGA 122PPI 800cd/m2 Industrial Lcd Monitor G065VN01 V2
6.5" 640×480 VGA 122PPI 800cd/m2 Industrial Lcd Monitor G065VN01 V2 6.5" 640×480 VGA 122PPI 800cd/m2 Industrial Lcd Monitor G065VN01 V2 6.5" 640×480 VGA 122PPI 800cd/m2 Industrial Lcd Monitor G065VN01 V2 6.5" 640×480 VGA 122PPI 800cd/m2 Industrial Lcd Monitor G065VN01 V2 6.5" 640×480 VGA 122PPI 800cd/m2 Industrial Lcd Monitor G065VN01 V2

Large Image :  6.5" 640×480 VGA 122PPI 800cd/m2 Industrial Lcd Monitor G065VN01 V2

Product Details:
Place of Origin: China
Brand Name: auo
Certification: Rohs,CE,FCC
Model Number: G065VN01 V2
Payment & Shipping Terms:
Minimum Order Quantity: 1pcs
Price: Negotiation
Packaging Details: Industrial packing
Delivery Time: 4-5 working day
Payment Terms: T/T,W, Western Union, MoneyGram
Supply Ability: 3000pcs per week
Detailed Product Description
Quality: Brand New Original Package: Original Industrial Packing
Material: Glass Oled Color: 265K Colors
Model: WLED Style: Wide Screen High Resolution 640(RGB)×480 [QVGA] 122PPI
Brightness: 800cd Connector: 20PIN
Contrast Ratio: 600:1 Working Time: 50k Hours
High Light:

800cd/m2 Industrial Lcd Monitor

,

640×480 Industrial Lcd Monitor

,

G065VN01 V2

AUO 6.5inch industrial lcd panel 640(RGB)×480, VGA, 122PPI 800cd/m2 600:1 contrast ratio 20Pin 262k colors



G065VN01 V2 (Alias: G065VN01 V.2) is a 6.5" diagonal a-Si TFT-LCD display panel product from AU Optronics Corp. (hereafter called AUO), with an integral WLED backlight system, With LED Driver , without touch screen. It features an operating temperature range of -30 ~ 80°C , a storage temperature range of -30 ~ 80°C , and the maximal vibration level of 1.5G (14.7 m/s²). It's general features are summarized by einklcd in the following: Wide Temperature, Hight Brightness, Lamp Repaceable, WLED Backlight, Life ≥ 50K hours, With LED Driver, U/D,L/R Reverse, 6/8 bit, Glossy , EcoTR. Based on its features, einklcd recommend that this model be applied to Industrial, Outdoor High Brightness etc. According to the information stored in einklcd this model mass production on Q4, 2009, Now this model is in production.  We inputted this model's specification on Sep 28 2012 for the first time, and the latest update on Jul 29 2019. If you want to embed the LCM in your future product, einklcd strongly recommend that you should contact with AUO or it's agent to learn lateast production and specification detail of G065VN01 V2. The production status marked on einklcd.com is for reference only and should not be used as the basis for the user's decision making.









Panel Brand
AUO
Panel Model
G065VN01 V2
Panel Size
6.5"
Panel Type
a-Si TFT-LCD, LCM
Resolution
640(RGB)×480, VGA, 122PPI
Pixel Format
RGB Vertical Stripe
Display Area
132.48(W)×99.36(H) mm
Bezel Opening
135.9(W)×102.8(H) mm
Outline Size
153(W)×118(H) ×11.2(D) mm
Surface
Glare (Haze 0%), Hard coating (3H), Antireflection
Brightness
800 cd/m² (Typ.)
Contrast Ratio
600:1 (Typ.) (TM)
Viewing Angle
80/80/70/70 (Typ.)(CR≥10)
Display Mode
TN, Normally White, Transmissive
Best View on
6 o'clock
Response Time
15/10 (Typ.)(Tr/Td)
Display Colors
262K/16.2M 55% NTSC
Lamp Type
WLED , 50K hours , With LED Driver
Frequency
60Hz
Touch Screen
Without
Panel Weight
170g (Typ.)
Application
6.5" 640×480 VGA 122PPI 800cd/m2 Industrial Lcd Monitor G065VN01 V2 0 6.5" 640×480 VGA 122PPI 800cd/m2 Industrial Lcd Monitor G065VN01 V2 1
Signal Interface
LVDS (1 ch, 6/8-bit) , 20 pins Connector
Input Voltage
3.3V (Typ.)
Environment
Operating Temp.: -30 ~ 80 °C ; Storage Temp.: -30 ~ 80 °C

6.5" 640×480 VGA 122PPI 800cd/m2 Industrial Lcd Monitor G065VN01 V2 2
