LG 29Inch Desktop LCD Display Panel 2560x1080Pixels FHD 300CD/M2 IPS PC LCD Module

Name: LG 29Inch Desktop LCD Display Panel 2560x1080Pixels FHD 300CD/M2 IPS PC LCD Module
Brand: FOCUS VISION TECHNOLOGY LIMITED
SKU: LM290WW1-SSA1
Price: 30.00 USD
Availability: InStock

Brand Name:	LG
Model Number:	LM290WW1-SSA1
MOQ:	10pcs
Price:	Negotiation
Payment Terms:	T/T,W, Western Union, MoneyGram
Supply Ability:	3000pcs per week

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

Rohs,CE,FCC

Quality:

Brand New Original

Package:

Original Industrial Packing

Resolution:

2560*1080pixels

Style:

92PIN IPS

Brightness:

300CD/M2

Color:

16.7M

Contrast Ratio:

1000 :1

Working Life:

30K Hours

Screen Size:

29inch

Touch Screen:

Without

Packaging Details:

Industrial packing

Highlight:

29Inch LCD Display Panel

2560x1080Pixels PC LCD Module

300CD/M2 Desktop LCD Monitor

Product Description

LG 29-Inch Desktop LCD Display Panel LM290WW1-SSA1

High-performance 29-inch FHD LCD panel featuring 2560×1080 resolution, IPS technology, and 96 PPI density. Designed for desktop monitor applications with advanced display characteristics.

Product Overview

The LG LM290WW1-SSA1 is a 29.0-inch diagonal a-Si TFT-LCD display panel with integrated WLED backlight system. This panel features sRGB color gamut, 3-side borderless design, and is optimized for LG monitor 29UM65 applications.

Key Specifications

Brand & Model	LG Display Co., Ltd. LM290WW1-SSA1
Diagonal Size	29.0 inches
Panel Type	a-Si TFT-LCD, LCM
Resolution	2560(RGB)×1080 (CSHD), 96 PPI
Active Area	672.768(W)×283.824(H) mm
Outline Dimensions	693.6(W)×308.9(H)×17.5(D) mm
Brightness	300 cd/m² (Typical)
Viewing Angle	89/89/89/89 (Left/Right/Up/Down, CR≥10)
Display Colors	16.7M, 100% sRGB
Refresh Rate	75Hz standard, up to 240Hz with MEMC
Weight	3.40/3.57 kg (Typical/Maximum)

Technical Features

IPS technology with Normally Black, Transmissive display mode
Response Time: 14ms typical (G to G)
Surface: Antiglare with Hard coating (3H)
Contrast Ratio: 1000:1 typical
Lamp Type: 17S4P WLED, 30,000 hours lifespan
Signal Interface: LVDS (4 channel, 8-bit), 92-pin connector
Input Voltage: 12.0V typical
3-side borderless design with matte finish

Environmental Specifications

Operating Temperature	0°C to 50°C
Storage Temperature	-20°C to 60°C

Application

Primary application: Desktop Monitor. Originally designed for LG monitor 29UM65.

Important Note: This model entered mass production in Q4 2012 and is currently discontinued. For integration into future products, contact LG Display or their distributor for the latest production and specification details. Status information is for reference only and should not be used as the basis for decision making.
