SG2701B01-3 1920x1080 81PPI CSOT 27 Inch Lcd Destop Monitor

Brand Name:	CSOT
Model Number:	SG2701B01-3
MOQ:	10pcs
Price:	Negotiation
Packaging Details:	industrial package
Payment Terms:	Western Union, MoneyGram, T/T

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

CE,FCC,ROSH,UL,REACH

Material:

Glass

Size:

27inch

Constraction:

4000:1

Pixels:

1920*1080

Contactor:

61pin

Working Life:

30k Hours

Display Colors:

16.7M

Weight:

Supply Ability:

20000pcs per week

Highlight:

SG2701B01-3

27 Inch Lcd Display Monitor

Product Description

CSOT 27inch Destop monitor Gaming lcd SG2701B01-3 1920*1080Pixels 81PPI 61pin oringial brand new

Brand
CSOT
Model
SG2701B01-3

Diagonal Size
27.0 inch
Type
a-Si TFT-LCD, CELL

Pixel Format
1920(RGB)×1080 [FHD] 81PPI
Configuration
RGB Vertical Stripe

Active Area
597.888(H)×336.312(V) mm
Outline Dim.
608.888(H)×348.337(V) ×1.3(D) mm

Bezel Area
-
Treatment
Antiglare (Haze 25%)

Luminance
0 cd/m²
Contrast Ratio
4000:1 (Typ.) (TM)

View Direction
Symmetry
Response Time
12 (Typ.)(G to G)

Viewing Angle
89/89/89/89 (Typ.)(CR≥10)
Operating Mode
HVA, Normally Black, Transmissive

Plate Thickness
0.40+0.50 mm
Transmittance
4.6% (Typ.)(with Polarizer)

Support Color
16.7M 99% sRGB
Light Source
No B/L

Weight
-
Designed For

Frame Rate
165Hz
Touch Panel
Without

Interface Type
LVDS (4 ch, 8-bit) , 61 pins Connector
Power Supply
12.0V (Typ.)
Environment
Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C
