Brand Name: | PVI |
Model Number: | ED060SC4 |
MOQ: | 10pcs |
Price: | Negotiation |
Packaging Details: | Industrial packing |
Payment Terms: | T/T,W, Western Union, MoneyGram |
Brand PVI
Model ED060SC4
Diagonal Size 6.0 inch
TypeEPD, EPD Pixel Format800×600 [SVGA]
ConfigurationRectangle Active Area122.4(H)×90.6(V) mm
Outline Dim.137.9(H)×104.1(V) ×1.33(D) mm
Bezel Area- TreatmentAntiglare, Hard coating
Luminance- Contrast Ratio7:1 (Typ.) (RF)
View Direction- Response Time780 (Typ.)(update) Viewing Angle90/90/90/90 (Typ.)
Operating Mode Reflective
Support ColorGrayscale
Light SourceNo B/L
Weight35.0±5.0g
Frame Rate-
Touch PanelWithout
Interface Type 39 pins
Parallel Data (8-bit) ,
FPC Power Supply 3.3V (Typ.)
Environment Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -25 ~ 70 °C
