800*600 250CD/M2 Digital Photo Frame Lcd 125PPI 50 PIN EJ080NA-05B

Name: 800*600 250CD/M2 Digital Photo Frame Lcd 125PPI 50 PIN EJ080NA-05B
Brand: FOCUS VISION TECHNOLOGY LIMITED
SKU: EJ080NA-05B
Price: 30.00 USD
Availability: InStock

Brand Name:	innolux
Model Number:	EJ080NA-05B
MOQ:	10pcs
Price:	Negotiation
Payment Terms:	T/T,W, Western Union, MoneyGram
Supply Ability:	3000pcs per week

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

Rohs,CE,FCC

Quality:

Brand New Original

Package:

Original Industrial Packing

Brightnerss:

250CD/M2

Connector:

50P

Color:

262k

Contrast Ratio:

500:1

Working Life:

20K Hours

Touch Panel:

Without

Resolution:

800*600pixels

Packaging Details:

Industrial packing

Highlight:

250CD/M2 Digital Photo Frame Lcd

800*600 Digital Photo Frame Lcd

EJ080NA-05B

Product Description

innolux 8inch digital photo frame lcd EJ080NA-05B 800*600pixels 125PPI 50PIN 250CD/M2

Manufacturer: Innolux
Model Name: EJ080NA-05B

Screen Size: 8.0 inch
Screen Type: LCM, a-Si TFT-LCD

Pixel Number: 800(RGB)×600 (SVGA) 125PPI
Arrangement: RGB Vertical Stripe

Active Area(mm): 162 × 121.5 (H×V)
Outline(mm): 183 × 141 × 5.9 (H×V×D)

Bezel Area(mm): 164.8 × 124.3 (H×V)
Treatment: Antiglare

Luminance: 250 cd/m² (Typ.)
Contrast Ratio: 500 : 1 (Typ.) (TM)

Viewing Angle: 70/70/50/70 (Typ.)(CR≥10)
Response: 10/15 (Typ.)(Tr/Td) ms

Good View at: 6 o'clock
Work Mode: TN, Normally White, Transmissive

Color Depth: 262K/16.7M 50% NTSC
Backlight: 3S9P WLED , 20K hours , No Driver

Mass: 241g (Typ.)
Used for

Refresh Rate: 60Hz
Touchscreen: Without

Signal Type: Parallel RGB (1 ch, 6/8-bit) , FPC 50 pins

Voltage Supply: 3.3/10.4/16.0/-7.0V (Typ.)(VCC/AVDD/VGH/VGL)

Max. Ratings: Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C; All lcd will be deliveried before one by one full test to make sure the quality was qualified.
