Full View Industrial LCD Display LG 31.5" Desktop Screen 350cd/m2 LM315WR1-SSA1

I'm Online Chat Now
We visited their factory many times.Their workshop is very big and e ink display module are really great!

—— Chris

Our company have placed orders to Ridafone many times.They develop and produce all e ink LCD display items in good quality.

—— Picado Freddy

Full View Industrial LCD Display LG 31.5" Desktop Screen 350cd/m2 LM315WR1-SSA1

Full View Industrial LCD Display LG 31.5" Desktop Screen 350cd/m2 LM315WR1-SSA1
Full View Industrial LCD Display LG 31.5" Desktop Screen 350cd/m2 LM315WR1-SSA1 Full View Industrial LCD Display LG 31.5" Desktop Screen 350cd/m2 LM315WR1-SSA1 Full View Industrial LCD Display LG 31.5" Desktop Screen 350cd/m2 LM315WR1-SSA1

Large Image :  Full View Industrial LCD Display LG 31.5" Desktop Screen 350cd/m2 LM315WR1-SSA1 Get Best Price

Product Details:

Place of Origin: KOREA
Brand Name: LG
Certification: Rohs,CE,FCC
Model Number: LM315WR1-SSA1

Payment & Shipping Terms:

Minimum Order Quantity: 1pcs
Price: Negotiation
Packaging Details: Industrial packing
Delivery Time: 4-5 working day
Payment Terms: T/T,W, Western Union, MoneyGram
Supply Ability: 3000pcs per week
Detailed Product Description
Quality: Brand New Original Package: Original Industrial Packing
Material: Glass Oled Color: 16.7M Colors
Model: WLED Style: Wide Screen High Resolution 3840*2160
Brightness: 350cd Connector: 30pin
Contrast Ratio: 1300:1 Working Life: 30K Hours
High Light:

industrial panel pc touch screen

,

industrial computer monitor

Manufacturer
Screen Size
Pixel Number
Active Area(mm)
Bezel Area(mm)
Luminance
Viewing Angle
Good View at
Color Depth
Mass
Refresh Rate
LG Display
31.5 inch
3840(RGB)×2160 (UHD)
697.31 × 392.23 (H×V)
-
350 (Typ.)(cd/m²)
89/89/89/89 (Typ.)(CR≥10)
Symmetry
1.07B 72% (CIE1931)
TBD
60Hz
Model Name
Screen Type
Arrangement
Outline(mm)
Treatment
Contrast Ratio
Work Mode
Response
Backlight
Used for
Touchscreen
LM315WR1-SSA1
LCM , a-Si TFT-LCD
RGB Vertical Stripe
709.2 × 405.03 × 13.6 (H×V×D)
Antiglare (Haze 25%), Hard coating (3H)
1300 : 1 (Typ.) (TM)
IPS, Normally Black, Transmissive
14 (Typ.)(G to G) ms
17S4P WLED , 30K hours , No Driver
Without
Signal Type eDP (4 Lanes) , Connector , 30 pins
Voltage Supply 10.0V (Typ.)
Max. Ratings Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C



Full View Industrial LCD Display LG 31.5" Desktop Screen 350cd/m2 LM315WR1-SSA1 0Full View Industrial LCD Display LG 31.5" Desktop Screen 350cd/m2 LM315WR1-SSA1 1Full View Industrial LCD Display LG 31.5" Desktop Screen 350cd/m2 LM315WR1-SSA1 2



                                                    It's 250cd/m2 high brightness industrial lcd   Original package of AUO lcd panel.

                  All our LCD LED screen monitor module panel products will be full test one by one before sending .
