Product Details:
|
| Quality: | Brand New Original | Package: | Original Industrial Packing |
|---|---|---|---|
| Material: | Glass Oled | Color: | 16.7M Colors |
| Model: | WLED | Style: | Wide Screen High Resolution 1600*900 |
| Brightness: | 250cd | Connector: | 30pin |
| Contrast Ratio: | 1000:1 | Working Life: | 30K Hours |
| High Light: | smart touch screen monitor,high resolution touch screen monitor |
||
| Manufacturer | AUO | Model Name | M195RTN01.0 |
|---|---|---|---|
| Screen Size | 19.5 inch | Screen Type | LCM , a-Si TFT-LCD |
| Pixel Number | 1600(RGB)×900 (HD+) | Arrangement | RGB Vertical Stripe |
| Active Area(mm) | 433.92 × 236.34 (H×V) | Outline(mm) | 452 × 263 × 11 (H×V×D) |
| Bezel Area(mm) | 437.2 × 239.6 (H×V) | Treatment | Antiglare, Hard coating (3H) |
| Luminance | 250 cd/m² (Typ.) | Contrast Ratio | 1000 : 1 (Typ.) (TM) |
| Viewing Angle | 85/85/80/80 (Typ.)(CR≥10) | Response | 3.8/1.2 (Typ.)(Tr/Td) ms |
| Good View at | 6 o'clock | Work Mode | TN, Normally White, Transmissive |
| Color Depth | 16.7M 72% (CIE1931) | Backlight | 10S4P WLED , 30K hours , No Driver |
| Mass | 1.43Kgs (Typ.) | Used for |
|
| Refresh Rate | 60Hz | Touchscreen | Without |
| Signal Type | LVDS (2 ch, 8-bit) , Connector , 30 pins | ||
| Voltage Supply | 5.0V (Typ.) | ||
| Max. Ratings | Storage Temp.: -20 ~ 65 °C Operating Temp.: 0 ~ 50 °C | ||
It's 250cd/m2 lcd MODEL for computer,all-in-one computer,desktop,laptop lcd.
All our LCD LED screen monitor module panel products will be full test one by one before sending .
