Product Details:
Payment & Shipping Terms:
|
| Quality: | Brand New Original | Package: | Original Industrial Packing |
|---|---|---|---|
| Material: | Glass Oled | Color: | 1.07b Colors |
| Model: | WLED | Style: | Wide Screen High Resolution 3840*1080 |
| Brightness: | 700cd | Connector: | 56pin |
| Contrast Ratio: | 1100:1 | ||
| High Light: | bar type display,stretch monitor display |
||
Panel Brand
LG Display
Panel Model
LD880DEN-UKA2
Panel Size
88 inch
Panel Type
a-Si TFT-LCD, LCM
Resolution
3840(RGB)×1080
Pixel Format
RGB Vertical Stripe
Display Area
2148.48(W)×598.32(H) mm
Bezel Opening
2149.5(W)×599.4(H) mm
Outline Size
2158.3(W)×611.2(H) ×84.2(D) mm
Surface
Antiglare (Haze 3%), Hard coating (2H)
Brightness
700 cd/m² (Typ.)
Contrast Ratio
1100:1 (Typ.) (TM)
Viewing Angle
89/89/89/89 (Min.)(CR≥10)
Display Mode
IPS, Normally Black, Transmissive
Best View on
Symmetry
Response Time
8 (Typ.)(G to G)
Display Colors
1.07B 74% (CIE1931)
Lamp Type
WLED , 50K hours , With LED Driver
Frequency
60Hz
Touch Screen
Without
Panel Weight
24.5Kgs
Application
Signal Interface
V-by-One 8 lane , 56 pins , Connector
Input Voltage
12.0V (Typ.)
Environment
Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C
All our LCD LED screen monitor module panel products will be full test one by one before sending .
