AUO PC LCD Module Module 17 Inch Size M170ETN01 1 51 PIN 1280 * 1024 Pixels

We visited their factory many times.Their workshop is very big and e ink display module are really great!

—— Chris

Our company have placed orders to Ridafone many times.They develop and produce all e ink LCD display items in good quality.

—— Picado Freddy

I'm Online Chat Now

AUO PC LCD Module Module 17 Inch Size M170ETN01 1 51 PIN 1280 * 1024 Pixels

China AUO PC LCD Module Module 17 Inch Size M170ETN01 1 51 PIN 1280 * 1024 Pixels supplier
AUO PC LCD Module Module 17 Inch Size M170ETN01 1 51 PIN 1280 * 1024 Pixels supplier AUO PC LCD Module Module 17 Inch Size M170ETN01 1 51 PIN 1280 * 1024 Pixels supplier AUO PC LCD Module Module 17 Inch Size M170ETN01 1 51 PIN 1280 * 1024 Pixels supplier AUO PC LCD Module Module 17 Inch Size M170ETN01 1 51 PIN 1280 * 1024 Pixels supplier AUO PC LCD Module Module 17 Inch Size M170ETN01 1 51 PIN 1280 * 1024 Pixels supplier AUO PC LCD Module Module 17 Inch Size M170ETN01 1 51 PIN 1280 * 1024 Pixels supplier

Large Image :  AUO PC LCD Module Module 17 Inch Size M170ETN01 1 51 PIN 1280 * 1024 Pixels

Product Details:

Place of Origin: China
Brand Name: auo
Certification: Rohs,CE,FCC
Model Number: DV430FHM-NN0

Payment & Shipping Terms:

Minimum Order Quantity: 5pcs
Price: Negotiation
Packaging Details: Industrial packing
Delivery Time: 4-5 working day
Payment Terms: T/T,W, Western Union, MoneyGram
Supply Ability: 3000pcs per week
Contact Now
Detailed Product Description
Quality: Brand New Original Package: Original Industrial Packing
Material: Glass Brightness: 400ccd/m2
Resolution: 1920*1080pixels Contrast Ratio: 1200:1
Color: 16.7M Working Life: 30k Hours
Connector: 51P Touch Panel: Without

Manufacturer

AUO

Model Name

M170ETN01.1

Screen Size

17.0 inch

Screen Type

LCM , a-Si TFT-LCD

Pixel Number

1280(RGB)×1024 (SXGA)

Arrangement

RGB Vertical Stripe

Active Area(mm)

337.92 × 270.336 (H×V)

Outline(mm)

358.5 × 296.5 × 10.8 (H×V×D)

Bezel Area(mm)

341.72 × 274.14 (H×V)

Treatment

Antiglare, Hard coating (3H)

Luminance

250 cd/m² (Typ.)

Contrast Ratio

1000 : 1 (Typ.) (TM)

Viewing Angle

85/85/80/80 (Typ.)(CR≥10)

Response

3.8/1.2 (Typ.)(Tr/Td) ms

Good View at

6 o'clock

Work Mode

TN, Normally White, Transmissive

Color Depth

16.7M 72% (CIE1931)

Backlight

9S4P WLED , 30K hours , No Driver

Mass

1.27Kgs (Typ.)

Used for

AUO PC LCD Module Module 17 Inch Size M170ETN01 1 51 PIN 1280 * 1024 Pixels

Refresh Rate

60Hz

Touchscreen

Without

Signal Type

LVDS (2 ch, 8-bit) , Connector , 30 pins

Voltage Supply

5.0V (Typ.)

Max. Ratings

Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C



AUO PC LCD Module Module 17 Inch Size M170ETN01 1 51 PIN 1280 * 1024 PixelsAUO PC LCD Module Module 17 Inch Size M170ETN01 1 51 PIN 1280 * 1024 PixelsAUO PC LCD Module Module 17 Inch Size M170ETN01 1 51 PIN 1280 * 1024 PixelsAUO PC LCD Module Module 17 Inch Size M170ETN01 1 51 PIN 1280 * 1024 PixelsAUO PC LCD Module Module 17 Inch Size M170ETN01 1 51 PIN 1280 * 1024 Pixels

  • All Origianl product will be send to customer after full test one by one.
  • Spec details can be send to you via email,please contact us.
