32 Inch 69PPI 500cd/M2 AUO Digital Signage Display P320HVN02.0

32 Inch 69PPI 500cd/M2 AUO Digital Signage Display P320HVN02.0
32 Inch 69PPI 500cd/M2 AUO Digital Signage Display P320HVN02.0 32 Inch 69PPI 500cd/M2 AUO Digital Signage Display P320HVN02.0 32 Inch 69PPI 500cd/M2 AUO Digital Signage Display P320HVN02.0 32 Inch 69PPI 500cd/M2 AUO Digital Signage Display P320HVN02.0

Large Image :  32 Inch 69PPI 500cd/M2 AUO Digital Signage Display P320HVN02.0

Product Details:
Place of Origin: China
Brand Name: auo
Certification: Rohs,CE,FCC
Model Number: P320HVN02.0
Payment & Shipping Terms:
Minimum Order Quantity: 10pcs
Price: Negotiation
Packaging Details: Industrial packing
Delivery Time: 4-5 working day
Payment Terms: T/T,W, Western Union, MoneyGram
Supply Ability: 3000pcs per week

32 Inch 69PPI 500cd/M2 AUO Digital Signage Display P320HVN02.0

Description
Quality: Brand New Original Package: Original Industrial Packing
Material: Glass Oled Color: 1.07B Colors
Model: WLED Style: Wide Screen High Resolution 1920*1080PIXELS
Brightness: 500cd Connector: 51PIN
Contrast Ratio: 3000:1 Working Time: 50k Hours
Input Voltage: 12V Signal Type: LVDS
High Light:

500cd/M2 AUO Digital Signage Display

,

69PPI AUO Digital Signage Display

,

P320HVN02.0

32Inch AUO Digital signage lcd display screens P320HVN02.0 1920(RGB)×1080 (FHD) 69PPI 500cd/m² 51PIN 12V



P320HVN02.0 is a 32.0" diagonal a-Si TFT-LCD display panel product from AU Optronics Corp. (hereafter called AUO), with an integral WLED backlight system, With LED Driver , without touch screen. It features an operating temperature range of 0 ~ 50°C , a storage temperature range of -20 ~ 60°C , and the maximal vibration level of 1.0G (9.8 m/s²). It's general features are summarized by einklcd in the following: sRGB, Landscape / Portrait, WLED Backlight, Life ≥ 50K hours, With LED Driver, Matte . Based on its features, einklcd recommend that this model be applied to Digital Signage etc. According to the information stored in einklcd this model mass production on Q4, 2014, Now this model is in production.  We inputted this model's specification on Apr 30 2014 for the first time, and the latest update on Sep 27 2019. If you want to embed the LCM in your future product, einklcd strongly recommend that you should contact with AUO or it's agent to learn lateast production and specification detail of P320HVN02.0. The production status marked on einklcd.com is for reference only and should not be used as the basis for the user's decision making.





  • ManufacturerAUO
  • Model NameP320HVN02.0
  • Screen Size32.0 inch
  • Screen TypeLCM, a-Si TFT-LCD
  • Pixel Number1920(RGB)×1080 (FHD) 69PPI
  • ArrangementRGB Vertical Stripe
  • Active Area(mm)698.4 × 392.85 (H×V)
  • Outline(mm)719.2 × 413.7 × 24.8 (H×V×D)
  • Bezel Area(mm)703.4 × 397.9 (H×V)
  • TreatmentAntiglare (Haze 2%), Hard coating (3H)
  • Luminance500 cd/m² (Typ.)
  • Contrast Ratio3000 : 1 (Typ.) (TM)
  • Viewing Angle89/89/89/89 (Typ.)(CR≥10)
  • Response8 (Typ.)(G to G) ms
  • Good View atSymmetry
  • Work ModeAMVA3, Normally Black, Transmissive
  • Color Depth16.7M 99% sRGB
  • BacklightWLED , 50K hours , With LED Driver
  • Mass4.59Kgs (Typ.)
  • Used for32 Inch 69PPI 500cd/M2 AUO Digital Signage Display P320HVN02.0 0
  • Refresh Rate60Hz
  • TouchscreenWithout
  • Signal Type
  • LVDS (2 ch, 8-bit) , 51 pins Connector
  • Voltage Supply
  • 12.0V (Typ.)
  • Max. Ratings
  • Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C



32 Inch 69PPI 500cd/M2 AUO Digital Signage Display P320HVN02.0 132 Inch 69PPI 500cd/M2 AUO Digital Signage Display P320HVN02.0 232 Inch 69PPI 500cd/M2 AUO Digital Signage Display P320HVN02.0 3
