Product Details:
|
| Quality: | Brand New Original | Package: | Original Industrial Packing |
|---|---|---|---|
| Resolution: | 1920*1080pixels | Style: | 30PIN IPS |
| Brightness: | 400 CD/M2 | Color: | 16.7M |
| Contrast Ratio: | 800 :1 | Working Life: | 50K Hours |
| High Light: | 400cd/m² Industrial Lcd Screen,1920X1080 Industrial Lcd Screen,G133HAN01.0 |
||
| Panel Brand |
|---|
| Panel Size |
| Resolution |
| Display Area |
| Outline Size |
| Brightness |
| Viewing Angle |
| Best View on |
| Display Colors |
| Frequency |
| Weight |
| AUO |
| 13.3" |
| 1920(RGB)×1080, FHD, 166PPI |
| 293.472(W)×165.078(H) mm |
| 309.7(W)×184.1(H) ×10.1(D) mm |
| 400 cd/m² (Typ.) |
| 85/85/85/85 (Typ.)(CR≥10) |
| Symmetry |
| 16.7M 90% NTSC |
| 60Hz |
| 500g (Typ.) |
| Panel Model |
| Panel Type |
| Pixel Format |
| Bezel Opening |
| Surface |
| Contrast Ratio |
| Display Mode |
| Response Time |
| Lamp Type |
| Touch Screen |
| Application |
| G133HAN01.0 |
| a-Si TFT-LCD , LCM |
| RGB Vertical Stripe |
| 295.07(W)×166.68(H) mm |
| Antiglare |
| 800:1 (Typ.) (TM) |
| AHVA, Normally Black, Transmissive |
| 25 (Typ.)(Tr+Td) |
| WLED , 50K hours , With LED Driver |
| Without |
| Signal Interface | LVDS (2 ch, 8-bit) , 30 pins Connector |
|---|---|
| Input Voltage | 3.3V (Typ.) |
| Environment | Operating Temp.: 0 ~ 70 °C ; Storage Temp.: 0 ~ 70 °C |
G133HAN01.0 AUO 13.3inch industrial lcd model 1920*1080pixels 400 cd/m² 30pin for medical gaming and industrial use
G133HAN01.0 is a 13.3" diagonal a-Si TFT-LCD display panel product from AU Optronics Corp. (hereafter called AUO), with an integral WLED backlight system, With LED Driver , without touch screen. It features an operating temperature range of 0 ~ 70°C , a storage temperature range of 0 ~ 70°C , and the maximal vibration level of 1.5G (14.7 m/s²). It's general features are summarized by Einklcd in the following: Wide Color Gamut, DCI-P3, sRGB, WLED Backlight, Life ≥ 50K hours, With LED Driver, Reverse I/F, Matte . Based on its features, einklcd recommend that this model be applied to Industrial, Medical Imaging, Gaming etc. According to the information stored in einklcd this model mass production on Q3, 2016, Now this model is in production. We inputted this model's specification on Jul 7 2015 for the first time, and the latest update on Sep 18 2019. If you want to embed the LCM in your future product, einklcd strongly recommend that you should contact with AUO or it's agent to learn lateast production and specification detail of G133HAN01.0. The production status marked on einklcd.com is for reference only and should not be used as the basis for the user's decision making.
All we sell lcd will be full test one by one before delivery to make sure the quality is best !
